@rickard If anyone else wants me a chatgpt (98% chatgpt) did this

This basically uses a twist motion as a variable speed adjuster that keeps going after hitting value from flic (intended). For that reason the virtual volume/lights/blinds should not have a limiter, instead you configure the limiter here in main.js

All you need to do is set up a virtual adjuster in the flic app and this will log the output. You can always then send this over mqtt or such

// rateDetentController.js // // Key fixes in this version: // 1) Soft recenter while neutral-latched (prevents UP/DOWN asymmetry) // 2) Debounced "ease into fine mode" so jitter does NOT trigger fine mode // // No behavior changes elsewhere. function clamp(x, min, max) { return x < min ? min : (x > max ? max : x); } function sign(x) { return x > 0 ? 1 : (x < 0 ? -1 : 0); } class RateDetentController { constructor(cfg) { this.cfg = cfg || {}; this.tickMs = this.cfg.tickMs || 333; // Neutral hysteresis this.deadbandEnter = typeof this.cfg.deadbandEnter === "number" ? this.cfg.deadbandEnter : 5; this.deadbandExit = typeof this.cfg.deadbandExit === "number" ? this.cfg.deadbandExit : 9; // Speed tiers this.tier1MaxOff = typeof this.cfg.tier1MaxOff === "number" ? this.cfg.tier1MaxOff : 25; this.tier2MaxOff = typeof this.cfg.tier2MaxOff === "number" ? this.cfg.tier2MaxOff : 50; this.tierHys = typeof this.cfg.tierHys === "number" ? this.cfg.tierHys : 3; // Output clamp this.minOutPct = typeof this.cfg.minOutPct === "number" ? this.cfg.minOutPct : 0; this.maxOutPct = typeof this.cfg.maxOutPct === "number" ? this.cfg.maxOutPct : 100; // --- NEW: soft recenter tuning --- this.neutralRecenterAlpha = typeof this.cfg.neutralRecenterAlpha === "number" ? this.cfg.neutralRecenterAlpha : 0.08; // 8% per update while resting // --- NEW: debounce for easing into fine mode --- this.easeConfirmMs = typeof this.cfg.easeConfirmMs === "number" ? this.cfg.easeConfirmMs : 200; // State this.centerInPct = null; this.actualOutPct = typeof this.cfg.initialOutPct === "number" ? this.cfg.initialOutPct : null; this.fineMode = false; this.lastDir = 0; this.lastSpeed = 0; this.currentDir = 0; this.currentSpeed = 0; this.neutralLatched = false; this.speedLatched = 0; // For debouncing easing this._easeCandidateSince = null; this._easeCandidateDir = 0; this._lastIntentKey = null; this._timer = setInterval(() => this._tick(), this.tickMs); } _desiredSpeed(absOff) { if (absOff <= this.tier1MaxOff) return 1; if (absOff <= this.tier2MaxOff) return 2; return 3; } _updateLatchedSpeed(desired, absOff) { if (this.speedLatched === 0) { this.speedLatched = desired; return; } if (this.speedLatched === 1) { if (desired >= 2 && absOff >= (this.tier1MaxOff + this.tierHys)) this.speedLatched = 2; if (desired === 3 && absOff >= (this.tier2MaxOff + this.tierHys)) this.speedLatched = 3; return; } if (this.speedLatched === 2) { if (absOff <= (this.tier1MaxOff - this.tierHys)) { this.speedLatched = 1; return; } if (desired === 3 && absOff >= (this.tier2MaxOff + this.tierHys)) { this.speedLatched = 3; return; } return; } if (this.speedLatched === 3) { if (absOff <= (this.tier2MaxOff - this.tierHys)) this.speedLatched = 2; } } _baseIntent(rawInPct) { if (this.centerInPct === null) { this.centerInPct = rawInPct; this.neutralLatched = true; this.speedLatched = 0; return { dir: 0, speed: 0, desiredSpeed: 0, reason: "center set" }; } const off = rawInPct - this.centerInPct; const absOff = Math.abs(off); // --- Sticky neutral with SOFT RECENTER --- if (this.neutralLatched) { if (absOff <= this.deadbandExit) { // soft recenter while resting this.centerInPct = this.centerInPct + this.neutralRecenterAlpha * (rawInPct - this.centerInPct); this.speedLatched = 0; return { dir: 0, speed: 0, desiredSpeed: 0, reason: "deadband (latched)" }; } this.neutralLatched = false; } else { if (absOff <= this.deadbandEnter) { this.neutralLatched = true; this.speedLatched = 0; return { dir: 0, speed: 0, desiredSpeed: 0, reason: "deadband (enter)" }; } } const dir = sign(off); const desiredSpeed = this._desiredSpeed(absOff); this._updateLatchedSpeed(desiredSpeed, absOff); const speed = (this.speedLatched === 0) ? 1 : this.speedLatched; return { dir, speed, desiredSpeed, reason: "detent" }; } _applyFineMode(base) { const { dir, speed, desiredSpeed } = base; const now = Date.now(); const directionChanged = (this.lastDir !== 0 && dir !== 0 && dir !== this.lastDir); const hitNeutralFromIntent = (this.lastSpeed > 0 && speed === 0); // --- Debounced easing detection --- let easedConfirmed = false; const easingCandidate = (this.lastSpeed >= 2 && desiredSpeed > 0 && desiredSpeed < this.lastSpeed && dir === this.lastDir); if (easingCandidate) { if (this._easeCandidateSince === null) { this._easeCandidateSince = now; this._easeCandidateDir = dir; } else if ( this._easeCandidateDir === dir && (now - this._easeCandidateSince) >= this.easeConfirmMs ) { easedConfirmed = true; } } else { this._easeCandidateSince = null; this._easeCandidateDir = 0; } if (!this.fineMode && (directionChanged || hitNeutralFromIntent || easedConfirmed)) { this.fineMode = true; this._easeCandidateSince = null; if (speed === 0) return { dir: 0, speed: 0, note: "enter fine (neutral)" }; if (directionChanged) return { dir, speed: 1, note: "enter fine (turn)" }; if (easedConfirmed) return { dir, speed: 1, note: "enter fine (ease)" }; return { dir, speed: 1, note: "enter fine" }; } if (this.fineMode) { if (speed === 0) return { dir: 0, speed: 0, note: "fine mode" }; return { dir, speed: 1, note: "fine mode" }; } return { dir, speed, note: null }; } updateRaw(rawInPct) { if (typeof rawInPct !== "number") return null; if (this.actualOutPct === null) this.actualOutPct = this.minOutPct; if (this.centerInPct === null) this.centerInPct = rawInPct; const base = this._baseIntent(rawInPct); const applied = this._applyFineMode(base); this.currentDir = applied.dir; this.currentSpeed = applied.speed; const note = applied.note || base.reason || null; const key = this.currentDir + "|" + this.currentSpeed + "|" + (this.fineMode ? "F" : "-") + "|" + (this.neutralLatched ? "N" : "-") + "|" + (note || ""); const intentChanged = (key !== this._lastIntentKey); this._lastIntentKey = key; this.lastDir = this.currentDir; this.lastSpeed = this.currentSpeed; return { intentChanged, rawInPct, dir: this.currentDir, speed: this.currentSpeed, fineMode: this.fineMode, note }; } _tick() { if (this.actualOutPct === null) return; if (this.currentDir === 0 || this.currentSpeed === 0) return; this.actualOutPct = clamp( this.actualOutPct + (this.currentDir * this.currentSpeed), this.minOutPct, this.maxOutPct ); } getActualOutPct() { return (this.actualOutPct === null) ? null : Math.round(this.actualOutPct); } stop() { if (this._timer) { clearInterval(this._timer); this._timer = null; } return this.getActualOutPct(); } } module.exports = RateDetentController;

That can be tested with a main.js like this
